| Item: | Hinge Joint Knot Sheep Fencing | Knot Type: | Hinge Joint |
|---|---|---|---|
| Feature: | Long Life Service, Easy To Install | Height: | 0.8m To 1.8m |
| Roll Length: | 50m / 100m | Finishing: | Electro Or Hot Dipped Galvanized |
| Highlight: | field wire fence,woven wire fence |
||
Hinge Joint Knot Sheep Fencing Hot Dipped Galvanized For Animal Fence
Introduction:
Hinge Joint Knot Sheep Fence is a kind of woven wire fences, it utilizes a woven wire with a hinge joint knot.
The hinge joint knot is designed to give under pressure and spring back into shape with added flexibility and strength.
It is the most ideal wire fence for farm and ranch uses. The fence mesh opening can be square or rectangular spacing.
| 1.Material: galvanized carbon iron wire | 2.Type: woven wire fence |
| 3.Mesh Hole Opening: 6" / 12" | 4.Wire Diameter: 2mm / 2.5mm |
| 5.Fence Height: 0.8m - 1.8m | 6.Roll Length: 50m or 100m as standard |
| 7.Surface Treatment: Electric or Hot Dipped Galvanized | 8.Packed in rolls with plastic film. |
| Different Weaving Types | Hinge joint knot |
| Square deal | |
| Fixed knot | |
| V mesh |
Application of Grassland Fence:
| 1. To strip-graze pastures, turnips and rape. |
| 2. As interim permanent fence until a proper fence can be built. |
| 3. Keeps in goats, sheep, cattle and domestic dogs. |
| 4. To enclose male animals. |
| 5. To graze orchards and vineyards. |
| 6. Keeps out coyotes, dogs and bears. |
| 7. For temporary lanes for moving animals. |
Feature of Grassland Fence:
Specification List:
| Code | Inner Wire Guage | Top & Bottom Wire Guage | Wire Spacing | Fence Height | Roll Length | Roll Weight |
| 1 | 9 | 9 | 6" | 47" | 330' | 396lbs |
| 2 | 9 | 9 | 12" | 47" | 330' | 295lbs |
| 3 | 11 | 9 | 6" | 32" | 330' | 210lbs |
| 4 | 11 | 9 | 6" | 39" | 330' | 241lbs |
| 5 | 11 | 9 | 6" | 47" | 330' | 290lbs |
| 6 | 11 | 9 | 12" | 39" | 330' | 185lbs |
| 7 | 11 | 9 | 12" | 47" | 330' | 208lbs |
| 8 | 12.5 | 10 | 6" | 26" | 330' | 128lbs |
| 9 | 12.5 | 10 | 6" | 32" | 330' | 148lbs |
| 10 | 12.5 | 10 | 6" | 39" | 330' | 169lbs |
| 11 | 12.5 | 10 | 6" | 47" | 330' | 192lbs |
| 12 | 12.5 | 10 | 12" | 32" | 330' | 116lbs |
| 13 | 12.5 | 10 | 12" | 39" | 330' | 131lbs |
| 14 | 12.5 | 10 | 12" | 47" | 330' | 146lbs |
| 15 | 14.5 | 11 | 6" | 32" | 330' | 90lbs |
| 16 | 14.5 | 11 | 6" | 39" | 330' | 102lbs |
| 17 | 14.5 | 12.5 | 6" | 39" | 330' | 98lbs |
| 18 | 14.5 | 12.5 | 6" | 47" | 330' | 111lbs |
| 19 | 12.5 | 10.5 | 6" | 39" | 330' | 174lbs |
| 20 | 12.5 | 10.5 | 6" | 47" | 330' | 198lbs |
| 21 | 11 | 9 | 9" | 42" | 330' | 193lbs |
| 22 | 11 | 9 | 9" | 48" | 330' | 217lbs |
| 23 | 13 | 10.5 | 6" | 39" | 330' | 151lbs |
| 24 | 13 | 10.5 | 6" | 47" | 330' | 173lbs |
