Product Details:
Payment & Shipping Terms:
|
| Item Name: | Woven Crimped Wire Mesh | Wire Material: | Mild Wire, SS Wire, Aluminum Wire |
|---|---|---|---|
| Application: | Architecture, Construction | Wire Diameter: | 0.4-1.6mm |
| Roll Height: | 0.9m-1.5m | Mesh/inch: | 2 - 18 |
| Highlight: | 1.6mm stainless steel crimped mesh,filter screen stainless steel crimped mesh,1.6mm crimped wire mesh |
||
Steel Woven Net Crimped Wire Mesh For Filter Screen
Crimped Wire Mesh Description
1.Grid structure & Concise mesh surface
The mesh surface is smooth and neat, the mesh is uniform, the mesh number is standard, and the aperture is uniform
2. Optimized material and stable performance
It is not easy to rust, and it will keep bright and durable for a long time
3.Anti slip and wear-resistant, stable structure
Embossing technology is anti-skid and wear-resistant, without welding, stable structure, not easy to deform, firm and durable
4.Crimped wire mesh is available in roll or flat panel form.
| Material: Low carbon steel wire, aluminum wire, stainless steel wire |
| Mesh: 2mesh - 18mesh |
| Wire Diamter: 0.4-1.6mm |
| Roll Height: 0.9m-1.5m |
| Pattern: Square or rectangular grid |
| Process: Weaving after crimped |
| Surface Treatment: Electro galvanized, hot dip galvanized or powder coated |
Application Of Aluminum Crimped Wire Mesh
| Used as fencing |
| Used as filter |
| As BBQ wire mesh to roast for food or meat |
| As screen in mine, coal factory, construction, etc. |
Specification Of Aluminum Crimped Wire Mesh
| Mesh/ Inch | Wire Diameter mm | Weight Kg/m2 |
| 4 | 1.25mm | 3.2 |
| 5 | 0.65mm | 1 |
| 5 | 0.88mm | 1.9 |
| 6 | 0.55mm | 0.85 |
| 6 | 0.7mm | 1.5 |
| 6 | 1.1mm | 3.25 |
| 8 | 0.43mm | 0.75 |
| 8 | 0.6mm | 1.3 |
| 8 | 0.65mm | 1.7 |
| 8 | 1.0mm | 3.7 |
| 10 | 0.4mm | 0.75 |
| 10 | 0.6mm | 1.5 |
| 10 | 0.85mm | 3.75 |
| 12 | 0.4mm | 0.85 |
| 12 | 0.5mm | 1.5 |
| 12 | 0.75mm | 3.3 |
| 14 | 0.45mm | 1.4 |
| 14 | 0.4mm | 1.1 |
| 16 | 0.4mm | 1.1 |
| 16 | 0.35mm | 1 |
| 18 | 0.4mm | 1.4 |
NOTE:
1. The definition of mesh is the number of openings per linear inch.
2. The term opening represents the clear opening between two parallel wires.
FAQ:
1. I'm interested in your crimped wire mesh, can i get free sample?
Yes, we could supply samples for free, but customer should pay the express fee.
2. Could you make a special crimped wire mesh for me?
Yes, it can be made as your require.
3. How can i get a competitive price quickly?
The quick quotation depends on the detailed dimensions you supply.
