Product Details:
Payment & Shipping Terms:
|
| Product Name: | White Welded Bended Wire Mesh Fence | Surface Treatment: | PVC Coating |
|---|---|---|---|
| Surface Color: | White | Post Type: | Peach Post, Round Post, Square Post |
| Aperture: | 50-200mm | Maximum Panel Size: | 2.4m X 3m |
| Highlight: | wire net fencing,mesh panel fence |
||
White Welded Bended Wire Mesh Fence PVC Coating After Galvanized Treatment
The White Welded Bended Wire Mesh Fence is made of low carbon iron wire , the fencing panels are galvanised followed by powder coating . |
The color could be green , blue , white , etc. The ' V ' shaped design increases stability to the panel including panels , mesh gates and accessories . |
The post type could be round post, square post or peach post . |
It's used as Boundary and Security Fence in airport , highway , stadium , etc. |
The wire mesh fence is custom made by our factory , each fence panel comes with a post and accessories . |
Application:
Wire Mesh Fence is used for:
Feature:
Simple structure |
Beautiful appearance |
Strong and reliable security |
Wide view and easily installation |
Thoroughly sealed and protected against rust and corrosion |
It’s a semi-opaque fence due to the open weave |
It not obscure sunlight from either side of the fence |
Quick Detail:
Specification of wire mesh fence | |||
Mesh size | 50x100, 50x150, 50x200,55x100,55x200 | mm | |
Panel size | 2x0.63, 2x0.83, 2x1.03, 2x1.23, 2x1.43, | m(L x H) | |
Post dimension | 50x70, 70x100, 50x50, 60x60, (square hole) | mm | |
Wire diameter | 3-6mm as customer’s request | mm | |
Surface treatment | Galvanized or PVC coated | ||
Color | Green, blue, black, white, yellow,etc. | ||
Post shape | Peach post, square. Holland, T-type, Y-type post | ||
Modular fencing system | Panel size (L*H) mm | Post height mm | Number of bending folds |
2405*1270 | 1500 | 2 | |
2405*1570 | 1850 | 2 | |
2405*1720 | 2130 | 2 | |
2405*2000 | 2450 | 3 | |
NOTE: There’re common specifications of products. Non-standard can also be customized as customer's request.
| Post Shape | Post Size |
| Square Post | 50x70mm, 70x100mm, 50x50mm, 60x60mm |
| Round Post | 32mm, 36mm, 38mm, 40mm, 42mm, 48mm |
| Peach Post | 50x70mm, 70x100mm |
Production Process:
Wire Drawing → Wire Straightening & Wire Cutting → Welding → Folds / Curves Bending → Electric Galvanizing / Hot-dipped Galvanizing → Parkerizing → PVC Coating / Spraying → Packing → Loading
FAQ:
1. I'm interested in your product, is custom size available?
Yes, our factory is professional in producing kinds of wire mesh, the product could be customized as your request .
2. The quantity is not that big, is that OK?
Yes, you can send us message with the real quantity, we'll try our best to make this order for you. We'd like to make good relationship with more customers.
3. Can I get free samples?
Yes, we'd like to provide small pieces free samples, and customers pay for the express fee.
4. Can you provide OEM service?
Yes, all the products can be made as your require.
5. How can i get a competitive price quickly?
The quick quotation depends on the detailed dimensions you supply.
