Anping County Baodi Metal Mesh Co.,Ltd.
Be your good wire mesh supplier & OEM.
Sales & Support:
|
Product Details:
Payment & Shipping Terms:
|
| Item: | Crimped Square Aluminum Wire Mesh | Material: | Aluminum |
|---|---|---|---|
| Weave Type: | Intermediate Crimp | Wire Diameter: | 0.063" |
| Roll Height: | 36" - 60" | Mesh: | 1/2" |
| Highlight: | woven steel mesh,woven wire mesh screen |
||
Material: Aluminum wire
Mesh: 1/2"
Wire Diamter: 0.063"
Roll Height: 36" - 60"
Pattern: Square grid
Process: Weaving after crimped
Crimped Square Wire Mesh is made by crimped mesh machine, it's available in carbon steel, stainless steel alloys and aluminum alloys.
Manufactured in a wide variety of wire diameters, crimped wire mesh is produced in a square or rectangular mesh.
it's a kind of woven wire cloth. Crimped wire mesh is available in roll or flat panel form.
Different Weaving Type:
Type A: Double Crimp Screen
Type B: Single Intermediate Crimp Screen
Type C: Double Intermediate Crimp Screen
Type D: Lock Crimp Screen
Crimped Square Aluminum Wire Mesh Feature:
| firm structure |
| Accurate & uniform apertures |
| good strength |
|
economy cost
|
| High temperature resisting |
| acid resisting |
| alkali resisting |
| corrosion resisting |
Application Of Crimped Square Wire Mesh
Used as fencing
Used as filter
As screen in mine, coal factory, construction, etc.
As BBQ wire mesh to roast for food or meat
Specification List Of Crimped Wire Mesh
| Crimped Wire Mesh | ||
| Mesh/ Inch | Wire Diameter mm | Weight Kg/m2 |
| 4 | 1.25 | 3.2 |
| 5 | 0.65 | 1 |
| 5 | 0.88 | 1.9 |
| 6 | 0.55 | 0.85 |
| 6 | 0.7 | 1.5 |
| 6 | 1.1 | 3.25 |
| 8 | 0.43 | 0.75 |
| 8 | 0.6 | 1.3 |
| 8 | 0.65 | 1.7 |
| 8 | 1.0 | 3.7 |
| 10 | 0.4 | 0.75 |
| 10 | 0.6 | 1.5 |
| 10 | 0.85 | 3.75 |
| 12 | 0.4 | 0.85 |
| 12 | 0.5 | 1.5 |
| 12 | 0.75 | 3.3 |
| 14 | 0.45 | 1.4 |
| 14 | 0.4 | 1.1 |
| 16 | 0.4 | 1.1 |
| 16 | 0.35 | 1 |
| 18 | 0.4 | 1.4 |
NOTE:
1. The definition of mesh is the number of openings per linear inch.
2. The term opening represents the clear opening between two parallel wires.
3. The crimped wire mesh could be custom made by our factory.
FAQ:
1. I'm interested in your crimped wire mesh, can i get free sample?
Yes, we could supply samples for free, but customer should pay the express fee.
2. Could you make a special crimped wire mesh for me?
Yes, it can be made as your require.
3. How can i get a competitive price quickly?
The quick quotation depends on the detailed dimensions you supply.
