Anping County Baodi Metal Mesh Co.,Ltd.
Be your good wire mesh supplier & OEM.
Sales & Support:
|
Product Details:
Payment & Shipping Terms:
|
| Item Name: | Stainless Steel 304 Punching Plate | Material: | Stainless Steel 304 |
|---|---|---|---|
| Plate Type: | Punched Plate | Hole Diameter: | 0.8mm-25mm |
| Maximum Sheet Width: | 1m | Maximum Sheet Length: | 2m |
| Highlight: | perforated metal screen,perforated stainless sheet |
||
Stainless Steel 304 Punching Plate 2000 x 1000 x 1.5mm Round Hole 8mm
Punching Plate is also known as perforated metal, perforated plate, or perforated sheet.
It's a punched metal sheet with holes, such as round holes, square holes and slotted holes.
| Type | Punched metal sheet | Materials | Stainless Steel ( SS304, SS316 ) / Aluminum / Carbon Steel / Mild Steel |
| Hole Diameter | 0.8-25mm | Hole Shapes | Round hole / Square hole / Slotted hole / Oblong hole / Hexagonal hole |
| Sheet Thickness | 0.5mm-3.5mm | Sheet Size | 1.5m x 3m ( Maximum ) |
Punching Platehas been utilized across a variety of industries:
1. Chemical — Filters, centrifuges, drying machine baskets, battery separator plates, water screens, gas purifiers, liquid gas burning tubes, mine cages, coal washing, etc.
2. Food and beverage — Beehive construction, grain dryers, wine vats, fish farming, silo ventilation, sorting machines, fruit and vegetable juice presses, cheese molds, baking trays, coffee screens, etc.
3. Architectural — Infill panels, sunshade, cladding, column covers, metal signage, site amenities, fencing screens, etc.
4. Automotive — Air filters, oil filters, silencer tubes, radiator grilles, running boards, flooring, motorcycle silencers, ventilation grids, tractor engine ventilation, etc.
5. Construction — Ceiling noise protection, acoustic panels, stair treads, pipe guards, ventilation grilles, sun protection slats, facades, sign boards, etc.
| Sheet Material | Sheet Thickness (mm ) | Hole Dia.(mm) | Pitch (mm) | Sheet Width(m) | Sheet Length(m) | Porosity (%) | Weight (kg/m2) |
| Carbon Steel Punching Plate | 0.5 | 1 | 1 | Maximum Sheet Width 1.5m | Maximum Sheet Length 3m | 19.6 | 3.14 |
| 0.55 | 1.1 | 2.2 | 22.67 | 3.411 | |||
| 0.55 | 1.5 | 2.8 | 26.03 | 3.268 | |||
| 0.8 | 1.5 | 1.5 | 19.6 | 5 | |||
| 0.8 | 2 | 3.4 | 30.78 | 4.465 | |||
| 1.5 | 2 | 2 | 19.6 | 9.4 | |||
| 1.5 | 5 | 8.0 | 35.39 | 7.843 | |||
| 3 | 5 | 16 | 19.6 | 18.8 | |||
| Stainless Steel Punching Plate | 0.5 | 1 | 1 | Maximum Sheet Width 1.5m | Maximum Sheet Length 3m | 19.6 | 3.14 |
| 0.8 | 1.5 | 1.5 | 19.6 | 5 | |||
| 1 | 2 | 2 | 19.6 | 6.28 | |||
| 2 | 5 | 16 | 19.6 | 6.28 | |||
| Aluminum Punching Plate | 0.5 | 1 | 1 | Maximum width 1.5m | Maximum lenght 3m | 19.6 | 1.08 |
| 0.8 | 3 | 3 | 19.6 | 1.72 | |||
| 1.6 | 2 | 2 | 19.6 | 3.24 | |||
| 3 | 4 | 16 | 19.6 | 4.23 |
